| MRC |
Requirement Statement |
Characteristics |
| AAWH |
DISTANCE FROM LARGEST BEARING SURFACE OF HEAD TO END OF FIRST DIAMETER |
0.513 INCHES MINIMUM AND 0.615 INCHES MAXIMUM |
| CSNG |
EXTERNALLY RELIEVED BODY DIAMETER QUANTITY |
1 |
| AASB |
FASTENER LENGTH |
1.063 INCHES MINIMUM AND 1.125 INCHES MAXIMUM |
| AAWC |
FIRST DIAMETER FROM HEAD |
0.214 INCHES MINIMUM AND 0.224 INCHES MAXIMUM |
| AASU |
HEAD HEIGHT |
0.195 INCHES MINIMUM AND 0.211 INCHES MAXIMUM |
| AASK |
HEAD STYLE |
HEXAGON |
| MATT |
MATERIAL |
STEEL COMP 301 OVERALL OR STEEL COMP 302 OVERALL OR STEEL COMP 302B OVERALL OR STEEL COMP 303 OVERALL OR STEEL COMP 303F OVERALL OR STEEL COMP 303 PLUS X OVERALL OR STEEL COMP 303SE OVERALL OR STEEL COMP 304 OVERALL OR STEEL COMP 304L OVERALL OR STEEL COM |
| AHYM |
NOMINAL THREAD DIAMETER |
0.312 INCHES |
| ABQZ |
INTERNAL DRIVE STYLE |
SLOT |
| AATB |
WIDTH BETWEEN FLATS |
0.489 INCHES MINIMUM AND 0.500 INCHES MAXIMUM |
| STDC |
SURFACE TREATMENT DOCUMENT AND CLASSIFICATION |
QQ-P-35 FED SPEC SINGLE TREATMENT RESPONSE OVERALL |
| SFTT |
SURFACE TREATMENT |
PASSIVATE OVERALL |
| AAJD |
THREAD CLASS |
2A |
| AAJF |
THREAD DIRECTION |
RIGHT-HAND |
| AASA |
THREAD LENGTH |
0.510 INCHES MINIMUM AND 0.550 INCHES MAXIMUM |
| CMLP |
THREAD QUANTITY PER INCH |
18 |
| THSD |
THREAD SERIES DESIGNATOR |
UNC |
