| MRC |
Requirement Statement |
Characteristics |
| AASB |
FASTENER LENGTH |
2.156 INCHES MINIMUM AND 2.250 INCHES MAXIMUM |
| AASU |
HEAD HEIGHT |
0.150 INCHES MINIMUM AND 0.163 INCHES MAXIMUM |
| AASK |
HEAD STYLE |
HEXAGON |
| MDCL |
MATERIAL DOCUMENT AND CLASSIFICATION |
SAEJ429 GRADE 8 ASSN STD SINGLE MATERIAL RESPONSE OVERALL OR ASTMA354 GRADE BD ASSN STD SINGLE MATERIAL RESPONSE OVERALL |
| MATT |
MATERIAL |
STEEL OVERALL |
| CQBC |
MINIMUM TENSILE STRENGTH |
150000 POUNDS PER SQUARE INCH |
| AHYM |
NOMINAL THREAD DIAMETER |
0.250 INCHES |
| AATB |
WIDTH BETWEEN FLATS |
0.428 INCHES MINIMUM AND 0.438 INCHES MAXIMUM |
| CSYM |
SURFACE FINISH |
63.0 MICROINCHES THREADS |
| STDC |
SURFACE TREATMENT DOCUMENT AND CLASSIFICATION |
QQ-P-416,TY2CL3 FED SPEC SINGLE TREATMENT RESPONSE OVERALL |
| SFTT |
SURFACE TREATMENT |
CADMIUM OVERALL AND CHROMATE OVERALL |
| AAJD |
THREAD CLASS |
2A |
| AAJF |
THREAD DIRECTION |
RIGHT-HAND |
| AASA |
THREAD LENGTH |
0.750 INCHES MINIMUM AND 0.938 INCHES MAXIMUM |
| CMLP |
THREAD QUANTITY PER INCH |
20 |
| THSD |
THREAD SERIES DESIGNATOR |
UNC |
