| Mfg. Part # | Mfg. Name | CAGE | RNCC | RNVC | ISC | MSDS | SADC | DAC | HCC |
|---|---|---|---|---|---|---|---|---|---|
| MS20230BS3 | NATIONAL AEROSPACE STANDARDS | 80205 | 3 | 2 | 2 | ||||
| 5325002910293 | NATIONAL AEROSPACE STANDARDS | SCY13 | 5 | 9 | 2 | ||||
| MS20230BS3 | NATIONAL AEROSPACE STANDARDS | 96906 | 5 | 9 | 2 | ||||
| AN230BS3 | NATIONAL AEROSPACE STANDARDS | 88044 | 5 | 9 | 2 |
| MRC | Requirement Statement | Characteristics |
|---|---|---|
| ADBA | BARREL HEIGHT | 0.255 INCHES NOMINAL |
| AGLW | BARREL LARGEST OUTSIDE DIAMETER | 0.540 INCHES MINIMUM AND 0.550 INCHES MAXIMUM |
| AGLV | BARREL OUTSIDE DIAMETER | 0.625 INCHES MINIMUM AND 0.635 INCHES MAXIMUM |
| AGLU | BARREL STYLE | TAPERED ROUND TYPE |
| HUES | COLOR | ANY ACCEPTABLE OVERALL |
| AEPR | FLANGE OUTSIDE DIAMETER | 0.965 INCHES MINIMUM AND 0.975 INCHES MAXIMUM |
| CTCJ | FLANGE STYLE | FLANGE |
| ZZZT | NONDEFINITIVE SPEC/STD DATA | 3 TYPE AND 1 CLASS |
| MATT | III MATERIAL | COPPER ALLOY OVERALL |
| AAVV | WASHER STYLE | SINGLE ROW TOOTHED W/ FLANGE |
